Chapter11 PoE Configuration
9-5
Purpose
Step
Parameter
(Optional)
Configure the
threshold value of the
power utilization ratio
1. Use command of configure
2. Use command of pse usage-threshold threshold
disable : not
bind with the
time-range table
item, not power
in the tiem
configured
threshold :
threshold value
of power
utilization ratio,
integer, 1~99
timerange :
integer, 1-128
9.2.4 Check PoE Configuration Information
Purpose
This operation is mainly used to check the configured PoE function and its parameters
right or wrong.
Progress
According to the different purposes, execute corresponding step. Please refer to the
following table.
Purpose
Step
Parameter
Check the
configuration of
Switch being as the
PSE
1. Start device, input username and password to
enter the Privilege User View or use command of
disable to exit to the Common User View
2. Use command of show pse config
interface-number
: interface number,
integfer,
<1-12>/<1-18>
Check the
information of Switch
being as the PSE
1. Start device, input username and password to
enter the Privilege User View or use command of
disable to exit to the Common User View
2. Use command of show pse information
Check power
supply information of
all interfaces or the
detailed power supply
information of
designated interface
1. Start device, input username and password to
enter the Privilege User View or use command of
disable to exit to the Common User View
2. Use command of show pse interface or use
command of show pse interface fastethernet
interface-number
