Chapter2 Layer 2 Ethernet Configuration
2-7
Objective
Step
Parameter
broadcast | dlf } percent
percent-value
bandwidth granularity of
passing data packet is 64
Kpbs;
times: indicates times of
bandwidth granularity that the
passing data packet occupies;
percent: indicates
percentages of bandwidth
granularity that the passing
data packet occupies;
percent-value: indicates the
percentage value of
bandwidth granularity that the
passing data packet occupies;
Cancel the provision of
storm suppression
1. Use command of
configure to enter the Global
Configuration View;
2. Use command of
interface interface-type
interface-number to enter one
specified interface
configuration view;
3. Use command of no
storm-control { multicast |
broadcast | dlf }
2.2.2.7 Configure Ethernet Interface Rate Suppression Function
Background
There are particular situations that port rate is required to be controlled so that to
provide different bandwidth for different users. The function of rate suppression
provides such ability. The particular input/output bandwidth control granularity may be
different due to different interface type.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Parameter
Configure rate
suppression
function to Ethernet
port
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface interface-type
interface-number to enter one specified
interface configuration view;
3. Use command of rate-limit {in|out} [ ratio]
In default, the port
has no bandwidth
suppression.
in: bandwidth
suppression to port
ingress side;
out: bandwidth
suppression to port
egress side;
rate-limit: bandwidth
control rate, times of
64 kbps.
Cancel the rate
suppression
configuration to
Ethernet port
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface interface-type
interface-number to enter one specified
interface configuration view;
3. Use command of no rate-limit {in|out}
