Qtech QSW-2800v2 [62/230] Link aggregation configuration
![Qtech QSW-2800v2 [62/230] Link aggregation configuration](/views2/1596593/page62/bg3e.png)
Chapter2 Layer 2 Ethernet Configuration
2-17
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Parameter
Enable
ARP debug
Use command of debug arp { in | out | error
| all }
or
debug arp { dst-addr | src-addr } ip-
address
{ in | out | error | all
|dst-addr | src-addr }:
received packet, sent packet,
error packet and all packets.
ip-address: destination or
source IP address, dotted
decimal, form as IPv4:
A.B.C.D
Disable
ARP debug
Use command of no debug arp { in | out |
error | all }
or
no debug arp { dst-addr | src-addr } ip-
address
2.5 Link Aggregation Configuration
2.5.1 Interface Aggregation Introduction
Link aggregation is to aggregate multiple ports into one single aggregation trunk
group to implement egress load sharing of each member ports as well as provide high
connecting reliability. Link aggregation can be divided into manual aggregation,
dynamic aggregation and static LACP aggregation. Pots in a same aggregation trunk
group shall have a same port type, i.e., if one of the ports is electric/optical port, all the
others must be the same.
The QSW-2800 is currently supporting manual aggregation and static LACP
aggregation only.
2.5.2 Configure Aggregation Group
Background
Please make sure that there is no member port inside the Trunk group before altering Trunk group
work mode, otherwise, the change of work mode is unavailable. To delete existing member port,
please use the command no join trunk trunk-id under corresponding configuration view, or run
command remove interface-type interface-number under Trunk configuration view.
Purpose
