Chapter2 Layer 2 Ethernet Configuration
2-30
Parameter
Description
Value
priority
0~7
2.6.7 Configure VLAN Other Parameters
Purpose
User can choose to use this section operation to configure other VLAN related
parameters according to real situation.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Configure VLANIF
description
information
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface vlan vlan-id to create and enter the VLANIF
Configuration View;
3. Use command of description description to configure VLANIF
description information;
4. Done.
Configure VLAN
description
information
1. Use command of configure to enter the Global Configuration View;
2. Use command of vlan vlan-id1 [vlan-id2] to create one or more VLAN and
enter the VLAN Configuration View;
3. Use command of description description to configure VLAN description
information;
4. Done.
Modify single VLAN
state and VLAN state
in batches
1. Use command of configure to enter the Global Configuration View;
2. Use command of static-vlan vlan-id to modify single VLAN state and
VLAN state in batches;
3. Done.
Configure protocol
identification of the
current interface outer
Tag
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number or interface
eth-trunk trunk-number to enter the Interface Configuration View;
3. Use command of tpid { protocol-id | standard } to configure protocol
identification of the current interface outer Tag;Mo
4. Done.
Configure to deal
with unknown unicast
packet when VLAN
forwarding
1. Use command of configure to enter the Global Configuration View;
2. Use command of vlan vlan-id1 [vlan-id2] to create one or more VLAN and
enter the VLAN Configuration View;
3. Use command of unknown-unicast { forward | drop } to configure to
