Qtech QSW-2800v2 [125/230] Maintenance and debug
![Qtech QSW-2800v2 [125/230] Maintenance and debug](/views2/1596593/page125/bg7d.png)
Chapter5 QoS Configuration
5-6
5.2.3 Maintenance and Debug
Purpose
When queue scheduling and congestion of QoS function is abnormal, user can use
this operation to check or debug.
Process
According to different destination, please execute corresponding steps. Refer to the
following table.
Objective
Procedure
Check QoS
configuration
information of
interface
1. Use command of disable to exit to Normal User View, or use
command of configure to enter Global Configuration View, or use
command of interface tunnel tunnel-num to enter Tunnel Interface
Configuration View, or no use any command to keep the current
Privileged User View;
2. Use command of show cos interface or use command of show
cos interface fastethernet interface-number to display QoS
configuration information of interface;
3. End.
Attached List:
Parameter
Description
Value
interface-number
interface number
to be <1-12>/<1-18>
5.2.4 Example
5.2.4.1 Configure SP Scheduling
Network Requirements
Flow is from interface 1/0/1, 1/0/2, 1/0/3 of Host1 to Host2. There is congestion on
interface 1/0/1 of Host2. Require to use SP algorithm.
Network Diagram
