Chapter4 Router Configuration
4-1
Chapter4 Routing Configuration
4.1 Summary
This chapter introduces configurations of QSW-2800 Switch routing function, including
its background, basic configuration process and configuration examples.
This chapter includes the following section.
Content
Page
4.1 Summary
4-1
4.2 Static Routing Configuration
4-1
4.2 Static Routing Configuration
4.2.1 Static Routing Introduction
Static routing is a particular routing mechanism that requires configuration in manual
by the administrator.
When the network structure is simple, static routing can be qualified enough to deploy
so that to make the network working normally. The static routing is able to improve
network performance as well as guarantee bandwidth for important applications.
The disadvantage of static routing is that once there is failure or fault occurs in the
network, the static routing cannot change accordingly and automatically, the
intervention from the network administrator is required.
4.2.2 Configure Static Routing
Purpose
This section introduces how to provision static routing information of IPv4 and IPv6.
Process
According to the different purposes, execute corresponding step. Please refer to the
following table.
Purpose
Step
Parameter Description
