Chapter2 Layer 2 Ethernet Configuration
2-4
Objective
Step
not been taken effect yet, the command
„shutdown‟ and „no shutdown‟ can be
used for interface close and restart to
make the interface effective again.
interface-number to enter one specified
interface configuration view;
3. Use command of no shutdown to open
current Ethernet port.
2.2.2.3 Configure Ethernet Interface Duplex State
Background
If it is required that the port is able to receive data packet while sending, then the port
can be provisioned as full-duplex mode; if port receiving and sending data packet is
required to be separated, then it can be provisioned as half-duplex mode; similarly, if
the port is configured as auto-negotiation, the duplex mode can be automatically
negotiated by both the local port and peer port.
Precondition
Before using the command, the command „negotiation auto‟ must be used to
implement that only when the fast Ethernet port is working under non-auto-negotiation
mode that it can be configured as port duplex mode. Otherwise, there will be prompt
from the device as „%Info: Please configure negotiation auto disable first‟.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Parameter
Configure the
Ethernet port
working under
full-duplex mode
1. Use command of configure to enter
the Global Configuration View;
2. Use command of interface
interface-type interface-number to enter
one specified interface configuration view;
3. Use command of „duplex full‟ to
designate the port is working under full-
duplex mode
In default, when the
Ethernet port is working
under non-auto-negotiation
mode, its working mode is
full-duplex.
Configure the
Ethernet port
working under
half-duplex mode
1. Use command of configure to enter
the Global Configuration View;
2. Use command of interface
interface-type interface-number to enter
one specified interface configuration view;
3.Use command of „duplex half’ to
