Chapter7 Security Configuration
7-1
Chapter7
Security Configuration
7.1 Summary
This chapter mainly introduces related security configuration of QSW-2800 including
802.1x, AAA, RADIUS, ACL configuration and etc.
This chapter includes the following section.
Content
Page
7.1 Summary
7-1
7.2 ACL Configuration
7-1
7.2 ACL Configuration
In this section, ACL means access control list for IPv4 message, ACL6 means access control list for
IPv6 message.
7.2.1 ACL Introduction
ACL Function
User can configure rules and action of ACL (Access Control List) to determine which
kind of data is allowed to pass or to deny so as to control data transmission and to
improve network performance and guarantee service security.
ACL is a series of sequential rules and action composed of layer2 MAC and layer3 IP.
Using the rules to filter data packet according to the source and destination address
and port number of data. Applying ACL to QSW-2800, device determines which data
to be received or to deny and other action to deal with the data according the rules of
ACL.
ACL classification supported of QSW-2800
QSW-2800 supports Layer2 ACL, Layer3 ACL, Mixed ACL and Layer3 ACL6.
