Chapter2 Layer 2 Ethernet Configuration
2-46
Objective
Step
Parameter
Check VLAN
translation item
related
information
1. Use command of to enter the Common
User View or the Privilege User View;
2. Use one of the following commands.
show translation-vlan interface
show translation-vlan interface vlan-list
show translation-vlan interface all
show translation-vlan mapped
show translation-vlan mapped vlan-list
vlan-list: VLAN list,
optional parameter, support
to input multiple VLAN ID.
form as 1,3,5-10
2.7.4 Example
Network Requirement
In the access network, family user connects with SwitchA through family gateway and
access to the carrier network at last.
Voice service data of User1 is tagged VLAN10 and internet online business data is
tagged VLAN11 through the gateway. Internet online business data of User2 is tagged
VLAN12 through the gateway.
After passing the SwtichA, the voice service data with VLAN10 of User1 is transmitted
to be tagged VLAN100 of carrier operator and the internet online business data with
VLAN11 of User1 is transmitted to be tagged VLAN101 of carrier operator. The
internet online business data with VLAN12 of User2 is transmitted to be tagged
VLAN101.
