Chapter2 Layer 2 Ethernet Configuration
2-11
Objective
Step
Check Ethernet
Interface state
1. Enter the Common User View, the Privilege User View, the Global
Configuration View or Interface Configuration View;
2. Use command of show interface fastethernet interface-number
config
Check the basic
information of all
Ethernet Interface
sand trunk interface
1. Enter the Common User View, the Privilege User View, the Global
Configuration View or Interface Configuration View;
2. Use command of show interface verbose
2.2.3.3 Switch to Different Ethernet Interface Configuration View
Purpose
After configuring the attributes of the current interface, this section operation can be
used to configure attributes of other interfaces.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Switch to new Ethernet
Interface Configuration
View from current Ethernet
Interface Configuration
View
1. Use command of configure to enter the Global
Configuration View;
2. Use command of interface interface-type
interface-number to enter the Interface Configuration View;
3. Use command of switch fastethernet interface-number
2.3 MAC Table Configuration
In order to quickly forward message, Switch needs to maintain MAC address table. The
MAC address table includes the MAC address of device connected with Switch and the
interface number of Switch connected with the device. The dynamic item (not configured
manually) in the MAC address table is learned by Switch. The method of Switch learning
MAC address is as the following. If one port (supposed to be portA) receives a data frame,
Switch will analyze the source MAC address of this data frame (supposed to be MAC-
SOURCE) and consider that the message with the destination MAC address of MAC-
SOURCE can be forwarded by portA. If MAC-SOURCE has been existed in the MAC
address table, Switch will update the corresponding table. If MAC-SOURCE has not been
