9-1
Chapter9
PoE Configuration
9.1 Summary
The full name of PoE is Power over Ethernet. PoE means to supply electricity by
10BASE-T, 100BASE-TX and 1000BASE-T Ethernet network. Its longest reliable
power supply distance is 100 meters. In this way, it can effectively solve the problem
of centralized power supply for the IP telephone, wireless AP, portable charger, credit
card reader, camera, data acquisition terminal and etc. For these terminals, it does
not need to consider the indoor power system wiring problems. It can realize the
power supply for the equipment when they are in the access the network at the same
time. In general use, the current power supply of PoE has the uniform standards. As
long as we follow the released 802.3af or 802.3at standard, the different
manufactures matching problem can be solved.
This chapter includes the following section.
Content
Page
9.1 Summary
9-1
9.2 PoE Function Configuration
9-1
9.2 PoE Function Configuration
9.2.1 Enable or Disable PoE Power Supply Function
Purpose
User can enable or disable remote power supply function of interface according to the
network requirement by using the twisted pair for the external PD (Powered Device,
electrical equipment). It provides more possibility for the application of the Ethernet at
the access side.
Progress
According to the different purposes, execute corresponding step. Please refer to the
following table.
