Chapter7 Security Configuration
7-19
Parameter
Description
Value
PBS number
PBS item number
to be from 10000 to
4294967295
PIR number
PIR item number
to be from 8 to
4294967295
aware
response to rate limited rule and
coloring rule
-
blind
Not to response to rate limited rule
and coloring rule
-
counter number
counter number
to be from 1 to 1024
packet/byte|all
Data type, byte type of counter
-
green/red/greenred/gre
enyellow/redyellow|total
Display type of counter state,
including green, red, green/red,
green/yellow and red/yellow
-
red|yellow
Color of data packet
-
drop
to drop data packet
-
remark-dscp
to remark DSCP value
-
dscp
DSCP value
using integer with range of
from 0 to 63
using name, to be key
word of af11, af12, af13,
af21, af22, af23, af31, af32,
af33, af41, af42, af43, cs1,
cs2, cs3, cs4, cs5, cs6, cs7,
default or ef
remark-dot1p
to remark 802.1p priority
-
priority
802.1p priority value of VLAN Tag
to be from 0 to 7
7.2.7 Maintenance and Debug
Purpose
When ACL function is abnormal, user can use this operation to check or debug.
Process
According to different destination, please execute corresponding steps. Refer to the
following table.
Objective
Procedure
Clear ACL
statistic
1. Use command of configure to enter Global Configuration View;
2. Use the following commands to remark ACL filter counter;
