Chapter2 Layer 2 Ethernet Configuration
2-23
2.6 VLAN Configuration
2.6.1 VLAN Introduction
VLAN Meaning
Divide LAN (Local Area Network) into multiple subclasses in logic and each subclass
has its own broadcast domain that is VLAN (Virtual Local Area Network).
Generally speaking, VLAN divides the devices in the LAN into multiple network
segments logically but not physically to realize the isolated broadcast domains in a
LAN technologically.
VLAN Function
Isolate broadcast domain and reduce broadcast storm and enhance the security.
In the large scale of network, it can restrict the network fault in VLAN and
enhance the network robust.
fastethernet-1/0/2
Port Status: Up and bind
Flag: S – Device is sending Slow LACPDUs
F – Device is sending fast LACPDUs
Local information:
Mode Flags Priority AdminKey OperKey PortId State
active
32768 0x19
0x19
0x2 0xa9d7f8
Partner‟s information:
Port
2
Flags
F
SysPri PortPri AdminKey OperKey OperPort OperState DevID
32768
32768
0x0
0x19
0x2
0x9dfb6c 0x00046798185d
fastethernet-1/0/3
Port Status: Up and bind
Flag: S – Device is sending Slow LACPDUs
F – Device is sending fast LACPDUs
Local information:
Mode
active
Flags Priority AdminKey
32768 0x19
OperKey PortId State
0x19
0x3 0xa9d7f8
Partner‟s information:
Port Flags
3 F
SysPri
32768
PortPri AdminKey OperKey OperPort OperState DevID
32768
0x0
0x19
0x3
0x9dfb6c 0x00046798185d
