Chapter8 Reliability Configuration
8-29
Objective
Procedure
4. End.
Attached List:
Parameter
Description
Value
interface-number
Ethernet interface number
to be <1-12>/<1-18>
rlink-group-number
RLINK group number
to be from 1 to 16
master
Master interface
-
slave
Slave interface
-
sender
Sender interface
group-list
Mirror group list ID
to be from 1 to 8, form as 1,3-5
vlan-list
Protection VLAN list
Form as 1,3,10-20 to be from 1 to
4094
vlan-id
VLAN ID of protocol packet
to be from 1 to 4094
8.3.3 Configure Monitor Link Group Function
Background Information
Rules to configure MLink group:
One interface can be uplink interface of multiple MLINK groups.
One interface can only be downlink interface of one MLINK group.
One interface cannot be the uplink interface and downlink interface at the same time.
Interface which has joined in eth-trunk cannot join in MLINK group.
Purpose
To use the operation in this section to configure Monitor Link group and its basic
function to realize interface linkage function.
Process
According to different destination, please execute corresponding steps. Refer to the
following table.
Objective
Procedure
Create MLINK
group and enter its
configuration view
1. Use command of configure to enter Global Configuration View;
2. Use command of mlink group mlink-group-number to create MLINK group
and enter its configuration view; If MLINK group has existed already, use this
Attention:
