Chapter4 Router Configuration
3-19
Objective
Step
Check DHCP
Server address
conflict statistics
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp server conflict to check DHCP Server
address conflict statistics information;
3. Done.
Check DHCP
Server timeout
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp server expired to check DHCP Server
timeout information;
3. Done.
Check DHCP
Server statistics
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp server statistic to check DHCP Server
statistics information;
3. Done.
Check the
DHCP related
configuration
information of
some VLAN
interface
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp vlan vlan-id config to check the DHCP
related configuration information of some VLAN interface ;
3. Done.
Appendix List:
Parameter
Description
Value
vlan-id
VLAN ID
integer with range of 1~4094
3.2.9 Example
Network Requirement
DHCP Server assigns IP address dynamically for clients of different network segment.
The network segments of user are 10.1.1.0/24 and 10.1.2.1/24.
The detailed requirements are as follows.
