Chapter4 Router Configuration
3-18
Objective
Step
management
information of
address pool
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp lease-entry to check IP address lease
management information of address pool;
3. Done.
Check device all
DHCP address
pool configuration
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp pool to check device all DHCP address
pool configuration information;
3. Done.
Check DHCP
Relay server
configuration
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp relay to check DHCP Relay server
configuration information;
3. Done.
Check DHCP
Relay statistics
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp relay statistic to check DHCP Relay
statistics information;
3. Done.
Check user
table information
of DHCP Relay
(including
dynamic and static
information)
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp relay user to check user table
information of DHCP Relay;
3. Done.
Check DHCP
Server
configuration
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp server to Check DHCP Server
configuration information;
3. Done.
