Chapter5 QoS Configuration
5-5
Objective
Procedure
interface queue
Interface Configuration View;
3. Use command of cos scheduling { sp | rr | wrr | drr } or use
command of cos scheduling { sp+rr | sp+wrr | sp+drr } queue-list to
configure scheduling mode of interface queue;
4. End.
(Optional)
Configure queue
weight of interface
1. Use command of configure to enter Global Configuration View;
2. Use command of interface fastethernet interface-number to enter
Interface Configuration View;
3. Use command of cos queue queue-number weight weight or use
command of cos queue queue-list weight weight to configure queue
weight of interface;
4. End.
(Optional)
Configure effective
bandwidth of queue
1. Use command of configure to enter Global Configuration View;
2. Use command of interface fastethernet interface-number to enter
Interface Configuration View;
3. Use command of cos queue { queue-number | queue-list }
{ min-bandwidth | max-bandwidth } 64kbps bandwidth-value1 or use
command of cos queue { queue-number | queue-list } { min-bandwidth
| max-bandwidth } mbps bandwidth-value2 to configure effective
bandwidth of queue;
4. End.
Attached List:
Parameter
Description
Value
1
queue number to be 1
-
8
queue number to be 8
-
queue-number
queue number
to be from 0 to 7
priority
priority item
to be from 0 to 7
default
default value
1
queue-list
queue list
form as 1,2, to be from 0 to
7
weight
weight item
to be from 0 to100
sp
Strict Priority
-
rr
Round Robin
-
wrr
Weighted Round Robin
-
drr
Deficit Round Robin
-
bandwidth-value1
specify 64Kbps granularity bandwidth
to be from 1 to 16000
bandwidth-value2
specify 1Mbps granularity bandwidth
to be from 1 to1000
