Chapter2 Layer 2 Ethernet Configuration
2-18
Operations in this section can be used to provision Trunk group with its basic
functions, as well as add member ports for enhancement of bandwidth and reliability.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Create Trunk
and enter its
configuration
view
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface trunk trunk-id to create aggregation group
and enter its configuration view, if the group to be created has existed already,
then enter its configuration view directly;
3. Done.
Configure
Trunk working
mode to be
static LACP
mode
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface trunk trunk-id to enter the Trunk Interface
Configuration View
3. Use command of mode lacp-static to configure Trunk working mode to
be static LACP mode;
4. Done.
Add member
interface into
Trunk
Method1:
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface trunk trunk-id to enter the Trunk Interface
Configuration View;
3. Use command of add interface-type { interface-number1 [ to
interface-number2 ] } to add member interface;
4. Done.
Method2:
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface interface-type interface-number to enter the
Interface Configuration View;
3. Use command of join trunk trunk-id to add the current interface into
Trunk;
4. Done.
(Optional)
Configure the
load sharing
mode
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface trunk trunk-id, to access trunk interface
view;
3. Use command of load-balance { dst-ip | dst-mac | src-ip | src-mac | src-
dst-ip | src-dst-mac } to configure the load sharing mode of trunk;
4. Done.
(Optional)
Configure the high threshold value of active interface.
