Chapter11 PoE Configuration
9-4
According to the different purposes, execute corresponding step. Please refer to the
following table.
Purpose
Step
Parameter
(Optional)
Configure the
description
information of the
device to be powered
1. Use command of configure
2. Use command of interface fastethernet
interface-number or use command of interface
fastethernet interface-number to fastethernet
interface-number
3. Use command of pse description description
interface-num
ber : interface
number, integer,
<1-12>/<1-18>
description:
description
information,
character string,
1~64 characters
enable: make
non-standard
PD function
detection
effective
power-value:
the maximum
power ration of
interface,
integer,
1~30000, unit:
milliwatt
low : the low
priority
high : the high
priority
critical : the
highest priority
none : cancel
to bind with the
time-range table
item
enable : bind
with the
time-range table
item, power in
the time
configured
(Optional) Enable
to detect
non-standard PD
function
1. Use command of configure
2. Use command of interface fastethernet
interface-number or use command of interface
fastethernet interface-number to fastethernet
interface-number
3. Use command of pse legacy enable
(Optional)
Configure the
maximum rated
power ratio
1. Use command of configure
2. Use command of interface fastethernet
interface-number or use command of interface
fastethernet interface-number to fastethernet
interface-number
3. Use command of pse max power power-value
(Optional)
Configure the priority
of device interface
power supply
1. Use command of configure
2. Use command of interface fastethernet
interface-number or use command of interface
fastethernet interface-number to fastethernet
interface-number
3. Use command of pse power-priority { low | high
| critical }
(Optional)
Configure power
shutdown time range
of device interface
1. After the step1, please enter the Global
Configuration View
2. Use command of interface fastethernet
interface-number or use command of interface
fastethernet interface-number to fastethernet
interface-number
3. Use command of pse shutdown time-range
timerange
(Optional) Enable
or disable the trap
alarm function of
PSE
1. Use command of configure
2. Use command of pse snmp-trap { enable |
disable }
