Chapter8 Reliability Configuration
8-26
SwitchD(config-fe2/1)#stp enable
SwitchD(config-fe2/1)#quit
SwitchD(config)#interface fastethernet1/2
SwitchD(config-fe1/2)#port link-type trunk
SwitchD(config-fe1/2)#port trunk allow-pass vlan 1-20
SwitchD(config-fe1/2)#stp enable
SwitchD(config-fe1/2)#quit
SwitchC(config)#interface fastethernet1/1
SwitchC(config-fe1/1)#stp enable
SwitchC(config-fe1/1)#edged-port enable
SwitchC(config-fe1/1)#port hybrid pvid 10
SwitchC(config-fe1/1)#port hybrid vlan 10 untagged
SwitchC(config-fe1/1)#quit
SwitchC(config)#
8.3 RLINK Configuration
8.3.1 RLINK Introduction
RLINK Background
Double uplink network is used to provide link backup. Usually use STP to block
redundancy link to eliminate loop so as to avoid broadcast storm. But its performance
cannot meet user‟s need and is not suitable for the network environment of high
requirement for convergence time. For the above reason, we propose RLINK solution.
Resilient Link
RLINK is resilient link. The solution is specially designed for double uplink network to
realize main-standby redundancy backup and fast switching.
Monitor Link
MLINK is monitor link. It is an interface linkage solution for RLINK. It makes RLINK
work under more safe and steady environment.
RLINK uses MLINK function to monitor uplink in order to achieve the purpose of uplink
and downlink synchronization. After uplink is fault, Monitor Link group will shut down
downlink automatically. After uplink recovers, downlink will also recover.
