Qtech QSW-2800v2 [69/230] Create vlan
![Qtech QSW-2800v2 [69/230] Create vlan](/views2/1596593/page69/bg45.png)
Chapter2 Layer 2 Ethernet Configuration
2-24
2.6.2 Create VLAN
Purpose
This section introduces how to create VLAN and it is the basic precondition for other
VLAN function configuration.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Create and enter
the VLANIF
Configuration View
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface vlan vlan-id to create and enter the VLANIF
Configuration View;
3. Done.
Delete the
specified VLANIF
1. Use command of configure to enter the Global Configuration View;
2. Use command of no interface vlan vlan-id to delete the specified VLANIF
View;
3. Done.
Create VLAN and
enter the VLAN
Configuration View
1. Use command of configure to enter the Global Configuration View;
2. Use command of vlan vlan-id1 [vlan-id2] to create one or more VLAN and
enter the VLAN Configuration View;
3. Done.
Delete one VLAN
or VLAN in batches
1. Use command of configure to enter the Global Configuration View;
2. Use command of no vlan vlan-id1 [vlan-id2] to delete one VLAN or VLAN
in batches;
3. Done.
Switch VLAN
configuration view
1. Use command of configure to enter the Global Configuration View;
2. Use command of vlan vlan-id1 [vlan-id2] to create one or moer VLAN and
enter the VLAN Configuration View;
3. Use command of switch vlan vlan-id to create other VLAN in VLAN
Configuration View and enter the created VLAN Configuration View;
4. Done.
Appendix List:
Parameter
Description
Value
vlan-id
VLAN ID
integer with range of 1~4094
2.6.3 Configure VLAN Based on Interface
Purpose
