Chapter7 Security Configuration
7-10
Parameter
Description
Value
information of ACL rule
dst-ip-mask| any
Destination IP address
mask information of ACL rule
dotted decimal
tos-priority
Priority of TOS segment
to be from 0 to 7
dscp
DSCP value
using integer with range of from 0 to 63
using name, to be key word of af11,
af12, af13, af21, af22, af23, af31, af32,
af33, af41, af42, af43, cs1, cs2, cs3, cs4,
cs5, cs6, cs7, default or ef
tos field
ToS segment of ACL rule
to be from 0 to 7
fragment
Whether the rule is
effective for non-head
fragment message
-
proto-type field
protocol type segment of
ACL rule
to be from 1 to 255
ttl field
TTL segment of ACL rule
to be from 1 to 255
7.2.4 Configure Mixed ACL
Background Information
One ACL is composed of some rules and actions.
Before configuring Mixed ACL rules, first need to create one Mixed ACL and specify
ACL type number to be from 2001 to 3000.
Process
According to different destination, please execute corresponding steps. Refer to the
following table.
Objective
Procedure
Create one mixed
ACL
1. Use command of configure to enter Global Configuration View;
2. Use command of filter-list acl-number to create one mixed ACL and
enter Mixed ACL Configuration View;
3. End.
Configure mixed
ACL rule
1. Use command of configure to enter Global Configuration View;
2. Use command of filter-list acl-number to enter Mixed ACL
Configuration View;
3. Under mixed mode, user can configure layer2 and layer3 ACL rule,
please refer to 7.2.2 and 7.2.3 of this manual;
