Chapter2 Layer 2 Ethernet Configuration
2-37
//Configure VLAN200 description information to be Market200.
SwitchB(config-vlan-200)#description Market200
//Add interface Ge1/0/1, Ge1/0/2, Ge1/0/3 and Ge1/0/4 into VLAN100 and configure
the VLAN100 to be the PVID of interface Ge1/0/1, Ge1/0/2 and Ge1/0/3.
SwitchB(config-vlan-100)#quit
SwitchB(config)#
SwitchB(config)#interface fastethernet 1/0/1
SwitchB(config-ge1/0/1)#port hybrid vlan 200 untagged
SwitchB(config-ge1/0/1)#port hybrid pvid 200
SwitchB(config-ge1/0/1)#quit
SwitchB(config)#interface fastethernet 1/0/2
SwitchB(config-ge1/0/2)#port hybrid vlan 200 untagged
SwitchB(config-ge1/0/2)#port hybrid pvid 200
SwitchB(config-ge1/0/2)#quit
SwitchB(config)#interface fastethernet 1/0/3
SwitchB(config-ge1/0/3)#port hybrid vlan 200 untagged
SwitchB(config-ge1/0/3)#port hybrid pvid 200
SwitchB(config-ge1/0/3)#quit
SwitchB(config)#interface fastethernet 1/0/4
SwitchB(config-ge1/0/4)#port hybrid vlan 200 tagged
SwitchB(config-ge1/0/4)#quit
SwitchB(config)#
2.7 VLAN Translation Configuration
2.7.1 Bind VLAN Translation Item with Interface
Purpose
This section introduces how to bind VLAN translation item to interface.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Parameter
