Chapter7 Security Configuration
7-5
Objective
Procedure
4. End.
Attached List:
Parameter
Description
Value
acl-number
Access Control List
number
to be from 1 to 4000
<1-1000>: layer2 ACL
<1001-2000>: IPv4ACL
<2001-3000>: Mixed ACL
<3001-4000>: IPv6ACL
rule-number
rule number of ACL
to be from 1 to 16384
src-mac-address/M| any
source MAC information
of ACL rule
M to be integer with range of from 1
to 24
any means any source MAC
address
dst-mac-address/M |any
destination MAC
information of ACL rule
M to be integer with range of from 1
to 24
any means any destination MAC
address
src-mac-mask
source MAC mask of
ACL rule
dotted decimal
dst-mac-mask
destination MAC mask of
ACL rule
dotted decimal
provider
(<1-4094>/<1-4094>)
(any|<0-7>) customer
(any|<1-4094>)(any|<0-7>)
VID/VID range or any
both all
-
rule-number
rule number of ACL
to be from 1 to16384
VLAN ID
VLAN ID
to be from 1 to 4094
7.2.3 Configure Layer3 ACL
Background Information
One ACL is composed of some rules and actions.
Before configuring Layer3 ACL rules, first need to create one Layer3 ACL and specify
ACL type number to be from 1001 to 2000.
Process
