Chapter8 Reliability Configuration
8-34
Objective
Procedure
information of all
or designated
interface
of configure to enter Global Configuration View, or use command of
interface fastethernet interface-number or interface eth-trunk trunk-
number to enter Interface Configuration View, or no use any command to
keep current Privileged User View;
2. Use command of show rlink interface or show rlink interface
fastethernet interface-number to display RLINK information of all or
designated interface
3. End.
Check MLINK
configuration
file information
1. Use command of disable to exit to Normal User View, or use command
of configure to enter Global Configuration View, or use command of
interface fastethernet interface-number or interface eth-trunk trunk-
number to enter Interface Configuration View, or no use any command to
keep current Privileged User View;
2. Use command of show mlink config to display configuration file
information of uplink monitoring function;
3. End.
Check
information of all
or designated
MLINK group
1. Use command of disable to exit to Normal User View, or use command
of configure to enter Global Configuration View, or use command of
interface fastethernet interface-number or interface eth-trunk trunk-
number to enter Interface Configuration View, or no use any command to
keep current Privileged User View;
2. Use command of show mlink group [ mlink-group-number ] to display
information of all or designated MLINK group;
3. End.
Check MLINK
information of all
or designated
interface
1. Use command of disable to exit to Normal User View, or use command
of configure to enter Global Configuration View, or use command of
interface fastethernet interface-number or interface eth-trunk trunk-
number to enter Interface Configuration View, or no use any command to
keep current Privileged User View;
2. Use command of show mlink interface or show mlink interface
fastethernet interface-number to display MLINK information of all or
designated interface;
3. End.
Attached List:
Parameter
Description
Value
receive
Packet received
-
send
Packet sent out
-
timer
timer
-
