Chapter8 Reliability Configuration
8-30
Objective
Procedure
command to enter its configuration view directly;
3. End.
Configure uplink
and downlink
interface of MLINK
group
1. Use command of configure to enter Global Configuration View;
2. Use command of interface fastethernet interface-number to enter
Interface Configuration View;
3. Use command of join mlink mlink-group-number role { uplink | downlink }
to add interface to MLINK group and designate the link of interface to be uplink
or downlink;
4. End.
Configure
interface whether to
enable MLINK
linkage function
1. Use command of configure to enter Global Configuration View;
2. Use command of interface fastethernet interface-number to enter
Interface Configuration View;
3. Use command of mlink { enable | disable } to enable or disable MLINK
linkage function of interface;
4. End.
Attached List:
Parameter
Description
Value
mlink-group-number
MLINK group number
to be from 1 to 16
interface-number
Ethernet interface number
to be <1-12>/<1-18>
uplink
Uplink member interface of MLINK group
-
downlink
Downlink member interface of MLINK group
-
8.3.4 Configure RLINK Other Related Parameter
Background Information
When there is fault in the main link of RLINK group, it will switch to standby link. After
the original main link fault recovers, in order to keep flow stability, the main link
keeps blocked state and do not preempt. If needing to recover it to be the main link,
user can use the following two methods.
Enable RLINK returning function, after returning timer terminating, it will switch to
the main link.
Use manual main-standby switching of RLINK group to enforce link switching.
