Qtech QSW-2800v2 [225/230] Configure power supply mode
![Qtech QSW-2800v2 [225/230] Configure power supply mode](/views2/1596593/page225/bge1.png)
Chapter11 PoE Configuration
9-2
Purpose
Step
Parameter
Enable
power supply
function of
device
Ethernet
interface
1. Use command of configure
2. Use command of interface fastethernet
interface-number or use command of interface
fastethernet interface-number to fastethernet
interface-number
3. Use command of pse enable
interface-number :
interface number,
integer,
<1-12>/<1-18>
enable: make the
remote power supply
function of device
effective
disable : make the
remote power supply
function of device
non-effective
Disable
power supply
function of
device
Ethernet
interface
1. Use command of configure
2. Use command of interface fastethernet
interface-number or use command of interface
fastethernet interface-number to fastethernet
interface-number
3. Use command of pse disable
9.2.2 Configure Power Supply mode
Background Information
QSW-2800-PE-PE supports four power supply modes. They are auto, force-
standard, force-high and half-auto.
Generally, it is recommended that user uses the default mode of half-auto.
When the device cannot supply electricity normally using non-standard PD in half-
auto mode, it is recommended that user uses the force-standard or force-high mode.
If using one of the two modes, user must enable the enhanced detection power supply
function.
Progress
According to the different purposes, execute corresponding step. Please refer to the
following table.
Purpose
Step
Parameter
Configure
interface power
supply mode of
device
1. Use command of configure
2. Use command of interface fastethernet
interface-number or use command of interface
fastethernet interface-number to fastethernet
interface-number
3. Use command of pse power-Management
{ auto | force-standard | force-high |
half-auto }
interface-numbe
r : interface
number, integer,
<1-12>/<1-18>
auto: automatic
mode of power
supply
force-standard:
forced standard
(Optional)Ena
1. Use command of configure
