Chapter4 Router Configuration
3-14
Parameter
Description
Value
pool
mac-address
user MAC address
form as AA:BB:CC:DD:EE:FF, A~F is
one hex
checktime
the maximum time of address
conflict detection
integer with range of 0~10000, unit:
millisecond
default
default value
500, unit: millisecond
3.2.7 Configure DHCP Relay
Purpose
Configure DHCP relay to realize IP address assigned to user of DHCP Server
crossing network.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Globally enable
DHCP function
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp start to globally enable DHCP function;
3. Done.
Configure DHCP
interface to work in
Relay mode
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface vlan vlan-id to enter the VLANIF
Configuration View;
3. Use command of ip dhcp relay to configure DHCP interface to
work in Relay mode;
4. Done.
Configure the
DHCP server IP
address of DHCP
relay agent
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface vlan vlan-id to enter the VLANIF
Configuration View;
3. Use command of dhcp relay server-ip ip-address to configure the
DHCP server IP address of DHCP relay agent ;
4. Done.
(Optional) Enable
or disable DHCP relay
to support option82
function
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface vlan vlan-id to enter the VLANIF
Configuration View;
3. Use command of dhcp option82 { enable | disable } to enable or
disable DHCP relay to support option82 function;
4. Done.
