Chapter8 Reliability Configuration
8-32
Objective
Procedure
Configuration View;
3. Use command of reverse-time time-value to configure returning
time of RLINK group;
4. End.
Configure sending
interval of protocol
packet
1. Use command of configure to enter Global Configuration View;
2. Use command of rlink group rlink-group-number to enter RLINK
Configuration View;
3. Use command of send-interval time-interval to confiugre sending
interval of protocol packet;
4. End.
Enable or disable
RLINK or MLINK trap
function
1. Use command of configure to enter Global Configuration View;
2. Use command of rlink group rlink-group-numbe to enter RLINK
Configuration View or use command of mlink group mlink-group-
number to enter MLINK Configuration View;
3. Use command of trap { enable | disable } to enalbe or disable
RLINK or MLINK trap function;
4. End.
Attached List:
Parameter
Description
Value
timeout-value
Overtime multiple value of receiving
the peer end protocol packet
to be from 10 to 50
time-value
Resilient Link returning time
to be from 3 to 60, unit:second
time-interval
Packet sending interval
to be from 50 to 10000,
unit:millisecond
8.3.5 Maintenance and Debug
Purpose
When RLINK function is abnormal, user can use this operation to check or debug.
Process
According to different destination, please execute corresponding steps. Refer to the
following table.
Objective
Procedure
Enable RLINK
debug function
1. Use command of disable to exit to Normal User View, or use command
of configure to enter Global Configuration View, or use command of
interface fastethernet interface-number or interface eth-trunk
