Chapter11 PoE Configuration
9-3
Purpose
Step
Parameter
ble the
enchanced
detection
function of
interface power
supply
2. Use command of interface fastethernet
interface-number or use command of interface
fastethernet interface-number to fastethernet
interface-number
3. Use command of pse enhance-detect
enable
mode of power
supply
force-high:
forced high power
mode
half-auto: half
automatic mode
enable: make
enhanced
detection power
supply function
effective
9.2.3 Configure PoE Power Supply Parameter
Background Information
Currently, QSW-2800-PE-PE only supports power supply in signal line mode, timing
power supply and power supply alarm function.
Configure the PD device description connected with the interface on the device. It is
convenient for user to manage the downstream PD device.
The PD device according with the 802.af protocol is the standard PD device. Usually,
PSE can only detect the standard PD and supply electricity for it. After enabling PSE
to detect the non-standard PD, PSE can detect the non-standard PD and supply
electricity for it.
PoE power supply port supports three priorities. The port priority ensures that the
critical equipment can be first powered when the power consumption of PD equipment
is greater than the total power supplied by the PSE. When the PSE power is
insufficient, if the priority of different ports is the same, it will order the priority
according to the interface number. The interface number is greater the priority is
higher and the port with greater interface number will be powered first.
The command of configuring the threshold power of PSE in the global configuration
view is used to protect the Switch to avoid the influence of the unstable power supply.
Progress
