Qtech QSW-2800v2 [156/230] Configure layer2 acl
![Qtech QSW-2800v2 [156/230] Configure layer2 acl](/views2/1596593/page156/bg9c.png)
Chapter7 Security Configuration
7-2
Layer2 ACL: Mainly based on source MAC, destination MAC, VLAN, priority,
protocol type, rate limitation template, time-range template and etc. to classify the
data.
Layer3 ACL: Mainly based on source IP, destination IP, source port number,
destination port number, protocol type, priority, fragment, lifetime, rate limitation
template, time-range template and etc. to classify the data.
Mixed ACL: Mainly based on source MAC, destination MAC, source IP,
destination IP, source port number, destination port number, protocol type, priority,
VLAN, rate limitation template, time-range template and etc. to classify the data.
Layer3 ACL6: Mainly based on source IPv6, destination IPv6, source port number,
destination port number, protocol type, hop limitation, the next head, traffic class,
flow flag, rate limitation template, time-range template and etc. to classify the
data.
7.2.2 Configure Layer2 ACL
Background Information
One ACL is composed of some rules and actions.
Before configuring Layer2 ACL rules, first need to create one Layer2 ACL and specify
ACL type number to be from 1 to 1000.
Process
According to different destination, please execute corresponding steps. Refer to the
following table.
Objective
Procedure
Create one layer2
ACL
1. Use command of configure to enter Global Configuration View;
2. Use command of filter-list acl-number to create one layer2 ACL and
enter Layer2 ACL Configuration View;
3. End.
Configure layer2
ACL rule
1. Use command of configure to enter Global Configuration View;
2. Use command of filter-list acl-number to enter Layer2 ACL
Configuration View;
3. Use the following commands to configure ACL rule matching MAC
(user chooses the following commands according to your need);
filter filter number mac (src-mac-address/M|any) (dst-mac-address/M
