Qtech QSW-2800v2 [47/230] Procedure
![Qtech QSW-2800v2 [47/230] Procedure](/views2/1596593/page47/bg2f.png)
Chapter2 Layer 2 Ethernet Configuration
2-3
2.2.2 Ethernet Interface Basic Attribute Configuration
2.2.2.1 Enter the Ethernet Interface View
Background
It needs to enter the Ethernet Interface Configuration View first and then configure the
Ethernet Interface.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Parameter
Enter the
Ethernet Interface
Configuration
View
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface
interface-type interface-number to enter
one specified interface configuration view.
interface-type:
fastethernet
interface-number:
<1-8>/<0-4>/<1-48>
Exit Ethernet
interface view
Use command of quit
-
2.2.2.2 Open/Shutdown Ethernet Interface
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Close Ethernet port
When the port is suspended, i.e., no
cable connected for data transmission,
please use command „shutdown‟ to close
the port so that to avoid abnormal working
status caused by disturbance.
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface interface-type
interface-number to enter one specified
interface configuration view;
3. Use command of shutdown to close
current Ethernet port.
Open Ethernet port
When parameters of interface property
are modified and new configuration has
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface interface-type
