![Qtech QSW-2800v2 [89/230] Appendix list](/views2/1596593/page89/bg59.png)
Chapter2 Layer 2 Ethernet Configuration
2-44
Objective
Step
Parameter
innervlan-id priority inner-priority [nto1]delete outer [nto1]
translation-vlan map-index outer-vlan { vlan-id |
vlan-id1/vlan-id2 } outer-pri priority { replace | add } { inner |
outer } VLAN-ID [nto1]
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } outer-pri priority { replace | add } { inner |
outer } VLAN-ID [nto1] priority PRIORITY
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } outer-pri priority { replace | add } inner
innervlan-id [nto1]{ replace | add } outer outervlan-id
[nto1]
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } outer-pri priority { replace | add } inner
innervlan-id priority inner-priority [nto1]{ replace | add }
outer outervlan-id
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } outer-pri priority { replace | add } inner
innervlan-id [nto1]{ replace | add } outer outervlan-id
priority outer-priority [nto1]
translation-vlan map-index outer-vlan { vlan-id | vlan-
id1/vlan-id2 } outer-pri priority { replace | add } inner
innervlan-id priority inner-priority [nto1] { replace | add }
outer outervlan-id priority outer-priority
Appendix List:
Parameter
Description
Value
map-index
VLAN translation item index
integer with range of
1~8192
inner-vlan
matching inner VLAN
-
vlan-id
specify VLAN ID to be matched
integer with range of
1~4094
vlan-id1/vlan-id2
specify VLAN range to be matched, 10/2 means
to match all VLAN of VLAN10~VLAN20, vlan-id2
must be more than vlan-id1
integer, vlan-id1 and
vlan-id2, to be 1~4094
delete
means to delete
-
inner
delete inner VLAN Tag
-
outer
delete outer VLAN Tag
-
delete inner
delete outer
delete inner and outer VLAN Tag
-
