Chapter7 Security Configuration
6-8
Objective
Step
3. Use command of igmp-snooping group-policy filter-list
filter-number version version-List to configure multicast policy;
4. Done.
(Optional)
Configure protocol
message
suppression
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping mvlan vlan-id to enter the
multicast VLAN configuration view;
3. Use command of igmp-snooping report-suppress { enable |
disable } to configure the enabled state of message suppression in VLAN;
4. Done.
(Optional)
Configure the
source IP of query
message
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping mvlan vlan-id to enter the
multicast VLAN configuration view;
3. Use command of igmp-snooping proxy-ip ip-address to configure the
source IP of query message, this configuration is effective only enabling
message suppression or working in proxy;
4. Done.
(Optional)
Configure
router-alert option
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping mvlan vlan-id to enter the
multicast VLAN configuration view;
3. Use command of igmp-snooping require-router-alert { enable |
disable } to configure router-alert requirement, only deal with the IGMP
message with router-alert option after enabling this function;
4. Done.
(Optional)
Configure
multicast VLAN
working mode
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping mvlan vlan-id to enter the
multicast VLAN configuration view;
3. Use command of igmp-snooping workmode { igmp-proxy | igmp-
snooping } to configure multicast VLAN working mode to be snooping or
proxy;
4. Done.
(Optional)
Configure
interface to leave
fast
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number to enter the
Interface Configuration View;
3. Use command of igmp-snooping fast-leave { enable | disable } to
configure interface to leave fast;
4. Done.
Appendix List:
Parameter
Description
Value
vlan-id
VLAN ID
integer, to be1-4094
