Chapter1 Basic Configuration
1-35
Purpose
Process
3. Done.
Parameter Description
Parameter
Description
Value
ipv4-address
Host IPv4 address
Dotted decimal
Ipv6-address
Host IPv6 address
Pure binary indication: 128 0s
and1s with 16 bits for each group
and 8 groups in total
remotefile
File name to be downloaded
from the host to server
String form with length 1~63
filename
Local file name to be uploaded
String form with length 1~63
[ port-id ]
Port number, optional
configuration
Integer form with range between
1~65535
1.4.2.5 TFTP Client Example
Purpose
This section introduces the example of switch as TFTP client implementing config file
backup and software upgrade.
Device
Configuration
Default
Value
Configuration Description
Switch
Use command „tftp‟ directly to
logging into remote TFTP server
for file upload/download
-
TFTP is applied for
environment with no complex
interaction between client and
server. Please make sure the
routing between switch and TFTP
server available.
PC
Start TFTP server with
configurations to TFTP category
-
-
Network Requirement
The switch as TFTP client and PC as TFTP server; the TFTP server has been TFTP
working category configured. Inband switch IP address is 1.1.1.1 and the port
connecting with switch and PC is belonging to particular VLAN; PC IP address is
1.1.1.2. Application program „switch.z‟ is saved in the PC. The switch downloads
„switch.z‟ from TFTP server through the TFTP and uploads switch config file to
