Chapter2 Layer 2 Ethernet Configuration
2-29
Objective
Step
3. Done.
Configure interface
to allow VLAN based
on protocol to pass
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number or interface
eth-trunk trunk-number to enter the Interface Configuration View;
3. Use command of port link-type hybrid to configure interface link type to
be hybrid;
4. Use command of port hybrid vlan vlan-list untagged } to configure
Hybrid type interface to join in the VLAN based on protocol;
Done.
Configure the
associated protocol
VLAN of interface
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number or interface
eth-trunk trunk-number to enter the Interface Configuration View;
3. Use command of protocol-vlan protocol-index vid vlan-id or use
command of protocol-vlan protocol-index vid vlan-id priority priority to
configure the associated protocol VLAN of interface;
4. Done.
Appendix List:
Parameter
Description
Value
protocol-index
protocol index value
integer with range of
1~16
ethernet-type-valu
e
divided VLAN based on other protocol type, the
protocol type is hex
hex, 0x600~0xffff
ethernet2
specify the encapsulated form of Ethernet
message to be Ethernet2
-
snap
specify the encapsulated form of Ethernet
message to be snap
-
llc
specify the encapsulated form of Ethernet
message to be llc
-
ssap
source service access point
-
dsap
destination service access point
-
any
any service access point
-
ssap-value
source service access point value
hex, 0x01~0xff
dsap-value
destination service access point value
hex, 0x01~0xff
protocol-index
protocol index value
integer with range of
1~16
vlan-id
the associated protocol VLAN ID
integer with range of
1~4094
priority
optional, specify the associated protocol VLAN ID
integer with range of
