Chapter8 Reliability Configuration
8-12
Objective
Procedure
4. Use command of stp instance instance-id vlan vlan-list to configure
applied VLAN of MSTI;
5. Use command of stp revision-level { range | default } to configure
MSTP revision level;
6. End.
Configure whether
to enable interface
STP function
1. Use command of configure to enter Global Configuration View;
2. Use command of interface fastethernet interface-number or
interface eth-trunk trunk-number to enter Interface Configuration View;
3. Use command of stp { enable | disable } to enable or disable
interface STP function;
4. End.
(Optional)
Configure priority of
Switch in designated
MSTI
1. Use command of configure to enter Global Configuration View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp instance instance-id priority { priority |
default } to configure priority of Switch in designated MSTI;
4. End.
(Optional)
Configure priority of
CIST instance 0
1. Use command of configure to enter Global Configuration View;
2. Use command of stp to enter STP Configuration View
3. Use command of stp priority { priority | default } to configure priority
of CIST instance 0;
4. End.
(Optional)
Configure interface
priority
1. Use command of configure to enter Global Configuration View;
2. Use command of interface fastethernet interface-number or
interface eth-trunk trunk-number to enter Interface Configuration View;
3. Use command of stp priority { priority | default } to configure
interface priority;
4. End.
Attached List:
Parameter
Description
Value
string
STP domain name
Character string without blank
instance-id
STP instance ID
to be from 1 to 63
range
STP revision level
to be from 0 to 65535
priority
QSW-2800 priority, the value is
smaller, the priority is higher
to be from 0 to 61440, step by 4096,
can configure number of 16 priority,
such as 0,4096, 8192 and etc.
customer
Bridge type to be customer mode
-
provider
Bridge type to be provider mode
-
priority
Interface priority
to be from 0 to 240
