Qtech QSW-2800v2 [45/230] According to the different purposes execute corresponding step please refer to the

Chapter1 Basic Configuration

1-38

To implement file download through device serial port with operation introduced in this

section.

Process

According to the different purposes, execute corresponding step. Please refer to the

following table.

Purpose

Step

Download

file from

device via

serial port

1. Use command of configure to enter the Global Configuration View;

2. Use command of zmodem get [ localfile filename] to download file from the

device via serial port;

3. Done.

Appended List:

Parameter

Description

Value

filename

Local file name to be downloaded

String for with length 1~63
