Qtech QSW-2800v2 [136/230] Configure controllable multicast
![Qtech QSW-2800v2 [136/230] Configure controllable multicast](/views2/1596593/page136/bg88.png)
Chapter7 Security Configuration
6-9
Parameter
Description
Value
interface-number
Ethernet interface port number
integer with range of
<1-8>/<0-4>/<1-48>
query-interval
time range of query interval
integer, to be10-65535
robust-count
the time of sending specific query
message, indicate the IGMP robust
coefficient of current VLAN
integer with range of 2-5
query-number
specific query time range
integer with range of 2-16
query-interval
specific query interval range
integer with range of 1-5, unit:
second
max-response-time
the maximum response time
range
integer with range of 1-25,
unit: second
ip-address
destination IP address
dotted decimal, form as
A.B.C.D, A~D is 0~255
6.2.5 Configure Controllable Multicast
Purpose
It is usually used in the multicast of Layer-2 scenarios to control IPTV program
number and guarantee the service quality of most users.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Configure IGMP
Snooping function
based on VLAN
The realization of controllable multicast base on IGMP Snooping
function, the configuration step of IGMP Snooping refers to 6.2.4;
Configure
controllable channel
parameter
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-control channel NAME mvlan vlan-Id
group-address groupIp source-address srcIp to create and configure
channel parameter (source-address is now non-effective provisionally);
3. Done.
(Optional)
Configure the
maximum user
number of
controllable channel
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-control channel NAME max-user-number
max-number to configure the maximum user number of controllable
channel;
3. Done.
Configure
1. Use command of configure to enter the Global Configuration View;
