Chapter2 Layer 2 Ethernet Configuration
2-9
Objective
Step
Parameter
interface
2. Use command of interface interface-type
interface-number to enter one specified
interface configuration view;
3. Use command of mtu mtu
byte
MTU default to be
1522
Recover to be the
default MTU
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface interface-type
interface-number to enter one specified
interface configuration view;
3. Use command of no mtu
2.2.2.10 Configure Cable Type Adaptation
Purpose
When the connection cable type of interface needs to match with the real used cable
type, it needs to configure the connected cable adaption method. Interface does not
support cross cable type default.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Configure interface
only to adapt crossing
cable type
1. Use command of configure to enter the Global Configuration
View;
2. Use command of interface interface-type interface-number
to enter one specified interface configuration view;
3. Use command of cross enable.
Configure interface
only to adapt direct cable
type
1. Use command of configure to enter the Global Configuration
View;
2. Use command of interface interface-type interface-number
to enter one specified interface configuration view;
3. Use command of cross disable.
2.2.2.11 Clear Current Ethernet Interface Statistics Information
Purpose
Use this section operation to clear the statistics information of current Ethernet
interface when there is a large amount of information to be cleared.
