Chapter7 Security Configuration
7-21
Objective
Procedure
trunk-number to enter Interface Configuration View; or use command of
filter-list acl-number to enter ACL Configuration View, or no use any
command to keep current Privileged User View;
2. Use command of show filter-list statistic to display ACL statistic
information;
3. End.
Check
information of
interface applied
ACL
1. Use command of disable to exit Normal User View; or use command
of configure to enter Global Configuration View; or use command of
interface fastethernet interface-number or interface eth-trunk trunk-
number to enter Interface Configuration View; or use command of filter-list
acl-number to enter ACL Configuration View, or no use any command to
keep current Privileged User View;
2. Use command of show filter-list interface to display information of
interface applied ACL;
3. End.
Check ACL
global
configuration
information
1. Use command of disable to exit Normal User View; or use command
of configure to enter Global Configuration View; or use command of
interface fastethernet interface-number or interface eth-trunk trunk-
number to enter Interface Configuration View; or use command of filter-list
acl-number to enter ACL Configuration View, or no use any command to
keep current Privileged User View;
2. Use command of show filter-list global to display ACL global
configuration information;
3. End.
Check statistic
table information
and configuration
information
1. Use command of disable to exit Normal User View; or use command
of configure to enter Global Configuration View; or no use any command to
keep current Privileged User View;
2. Use command of show counter config or show counter counter-id or
show counter to display statistic table information and configuration
information;
3. End.
Attached List:
Parameter
Description
Value
acl-number
Access Control List
to be from 1 to 4000
counter-id
Statistic table ID
to be from 1 to 1024
