Chapter2 Layer 2 Ethernet Configuration
2-6
Objective
Step
Parameter
Enable Ethernet
port flow control
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface interface-type
interface-number to enter one specified
interface configuration view;
3. Use command of flow –control enable
In default, the flow
control status of
Ethernet port is
disabled.
Disable Ethernet
port flow control
1. Use command of configure to enter the
Global Configuration View;
2. Use command of interface interface-type
interface-number to enter one specified
interface configuration view;
3. Use command of flow –control disable
2.2.2.6 Configure Ethernet Interface Broadcast/Multicast Message Suppression Function
Purpose
In order to prevent port congestion caused by flush of broadcast/multicast message,
the switch provides storm suppression function to broadcast/multicast message. The
user is allowed to restrain broadcast/multicast message by configuring bandwidth via
the command.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Parameter
Configure
broadcast/multicast/unknown
unicast storm message
suppression to Ethernet port.
1. Use command of
configure to enter the Global
Configuration View;
2. Use command of
interface interface-type
interface-number to enter one
specified interface
configuration view;
3. Use command of
storm-control { multicast |
broadcast | dlf } 64kbps
times
or
storm-control { multicast |
In default, port has no rate
limit to
broadcast/multicast/unknown
unicast message.
broadcast: to process storm
suppression to broadcast
message;
multicast: to process storm
suppression to multicast
message;
dlf : multicast: to process
storm suppression to
unknown unicast message;
64kbps: indicates the
