Chapter2 Layer 2 Ethernet Configuration
2-25
This section introduces how to configure VLAN based on interface.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Configure the
default VLAN of
interface and
configure the
interface to join in the
default VLAN
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number or interface
eth-trunk trunk-number to enter the Interface Configuration View;
3. Use command of port default vlan vlan-id to configure the default VLAN
of interface and configure the interface to join in the default VLAN;
4. Done.
Configure the
VLAN wich Hybrid
interface belongs to
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number or interface
eth-trunk trunk-number to enter the Interface Configuration View;
3. Use command of port hybrid vlan vlan-list { tagged | untagged } to
configure the VLAN which Hybrid interface belongs to;
4. Done.
Configure the
default VLAN of
Hybrid interface
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number or interface
eth-trunk trunk-number to enter the Interface Configuration View;
3. Use command of port hybrid pvid { vlan-id | default } to configure the
default VLAN of Hybrid interface;
4. Done.
Configure the link
type of interface
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number or interface
eth-trunk trunk-number to enter the Interface Configuration View;
3. Use command of port link-type { access | trunk | hybrid | default } to
configure the link type of interface;
4. Done.
Configure trunk
interface to join in
VLAN
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number or interface
eth-trunk trunk-number to enter the Interface Configuration View;
3. Use command of port trunk allow-pass vlan vlan-list to configure trunk
interface to join in VLAN;
4. Done.
Configure the
default VLAN of trunk
interface
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number or interface
eth-trunk trunk-number to enter the Interface Configuration View;
3. Use command of port trunk pvid { vlan-id | default } to configure the
