Chapter4 Router Configuration
3-15
Objective
Step
(Optional)
Configure the dealing
policy for the request
message sent by
DHCP Client with
option82 of DHCP
relay
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface vlan vlan-id to enter the VLANIF
Configuration View;
3. Use command of dhcp option82 { drop | keep | replace } to
configure the dealing policy for the request message sent by DHCP
Client with option82 of DHCP relay;
4. Done.
(Optional)
Configure the Circuit
ID of DHCP Option82
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface vlan vlan-id to enter the VLANIF
Configuration View;
3. Use command of dhcp option82 circuit-id circuited to configure
the Circuit ID of DHCP Option82
4. Done.
(Optional)
Configure the Remote
ID of DHCP Option82
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface vlan vlan-id to enter the VLANIF
Configuration View;
3. Use command of dhcp option82 remote-id remoteid to configure
the Remote ID of DHCP Option82;
4. Done.
(Optional)
Configure the static
user address binding
table of DHCP relay
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp relay static-bind ip-address mac-address
to configure the static user address binding table of DHCP relay;
3. Done.
(Optional)
Confiugre the timing
updating period of
DHCP relay user
table
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp relay user refresh-interval { interval |
default } to Confiugre the timing updating period of DHCP relay user
table ;
3. Done.
(Optional)
Configure DHCP
address matching
detection function
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface vlan vlan-id to enter the VLANIF
Configuration View;
3. Use command of dhcp address-check { enable | disable } to
Configure DHCP address matching detection function;
4. Done.
(Optional)
Configure DHCP fake
server detection
function
1. Use command of configure to enter the Global Configuration View;
2. Use command of dhcp server detect { enable | disable } to
configure DHCP fake server detection function;
3. Done.
