Chapter4 Router Configuration
3-17
Objective
Step
3. Done.
Enable DHCP
server debug
function
1. Keep the current Privilege User View;
2. Use command of debug dhcp server to enable DHCP server debug
function;
3. Done.
Enable DHCP
fake-server debug
function
1. Keep the current Privilege User View;
2. Use command of debug dhcp fake-server to enable DHCP fake-
server debug function;
3. Done.
Clear DHCP
relay statistics
information
1. Keep the current Privilege User View;
2. Use command of reset dhcp relay statistic to clear DHCP relay
statistics information;
3. Done.
Clear DHCP
server statistics
information
1. Keep the current Privilege User View;
2. Use command of reset dhcp server statistic to clear DHCP server
statistics information;
3. Done.
Check device
DHCP related
parameters
configuration
state information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp to check device DHCP related
parameters configuration state information;
3. Done.
Check device
DHCP
configuration
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp config to check device DHCP
configuration information;
3. Done.
Check device
DHCP user table
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show dhcp bind-entry to check device DHCP user
table information;
3. Done.
Check IP
address lease
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
