Chapter4 Router Configuration
4-2
Purpose
Step
Parameter Description
Configure
an IPv4
static route
1. Use command of configure to access global
configuration view;
2. Use command of ip route-static ip-address
mask-address nexthop-address or ip route-static
ip-address mask-address nexthop-address NAME
or ip route-static ip-address mask-address
nexthop-address metric <0-255> to configure an
IPv4 static route;
3. Done.
In default, system has no
static routing list
Delete
IPv4 static
route
1. Use command of configure to access global
configuration view;
2. Use command of no ip route-static ip-
address mask-address or no ip route-static ip-
address mask-address nexthop-address or no ip
route-static all to delete IPv4 static route;
3. Done.
Configure
an IPv6
static route
1. Use command of configure to access global
configuration view;
2. Use command of ipv6 route-static ipv6-
address mask-length ipv6- nexthop-address
VLAN VLAN ID to configure an IPv6 static route;
3. Done.
Delete
IPv6 static
route
1. Use command of configure to access global
configuration view;
2. Use command of no ipv6 route-static ipv6-
address mask-length to delete IPv6 static route;
or no ipv6 route-static all to delete all IPv6
static routes;
3. Done.
Enable or
disable IPv6
unicast
forwarding
1. Use command of configure to access global
configuration view;
2. Use command of ipv6 unicast-forwarding
{ enable | disable } to enable or disable IPv6
unicast forwarding;
3. Done.
Configure
IPv6 hop
limit
1. Use command of configure to access global
configuration view;
2. Use command of ipv6 hop-limit hop-limit
numbe to configure IPv6 hop limit;
