Chapter2 Layer 2 Ethernet Configuration
2-31
Objective
Step
deal with unknown unicast packet when VLAN forwarding ;
4. Done.
Configure to deal
with unknown unicast
packet when VLAN
forwarding
1. Use command of configure to enter the Global Configuration View;
2. Use command of unknown-unicast vlan vlan-list { forward | drop } or
use command of vlan vlan-list unknown-unicast { forward | drop } or use
command of vlan vlan-id unknown-unicast { forward | drop } to configure to
deal with unknown unicast packet when VLAN forwarding ;
3. Done.
Configure the
dealing of load
sharing mode in trunk
interface when VLAN
forwarding of
aggregation interface
1. Use command of configure to enter the Global Configuration View;
2. Use command of unknown-unicast load-balance
{ dst-mac|src-mac|srcdst-mac|schedule-profile name |default } to configure the
dealing of load sharing mode in trunk interface when VLAN forwarding of
aggregation interface ;
3. Done.
Configure to deal
with unknown
multicast when VLAN
forwarding
1. Use command of configure to enter the Global Configuration View;
2. Use command of Use command of vlan vlan-id1 [vlan-id2] to create one
or more VLAN and enter the VLAN Configuration View;
3. Use command of unknown-multicast { forward | drop } to configure to
deal with unknown multicast when VLAN forwarding;
4. Done.
Configure to deal
with unknown unicast
when VLAN
forwarding
1. Use command of configure to enter the Global Configuration View;
2. Use command of unknown-multicast vlan vlan-list { forward | drop } or
use command of vlan vlan-list unknown-multicast { forward | drop } or use
command of vlan vlan-id unknown-multicast { forward | drop } to configure
to deal with unknown unicast when VLAN forwarding;
3. Done.
Configure VLAN
matching priority of
interface
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface fastethernet interface-number or interface
eth-trunk trunk-number to enter the Interface Configuration View;
3. Use command of vlan precedence { mac-vlan | ip-subnet-vlan } to
configure VLAN matching priority of interface;
4. Done.
Configure VLAN
type to be common
VLAN
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface vlan vlan-id to create and enter the VLANIF
Configuration View or use command of vlan vlan-id1 [vlan-id2] to create one
or more VLAN and enter the VLAN Configuration View;
3. Use command of vlan normal to configure VLAN type to be common
VLAN;
4. Done.
