Chapter1 Basic Configuration
When logging into QSW-2800 Switch through Console port, the user needs to
connect to the Console port of QSW-2800 front panel with a serial line.
Process
The processes of logging into QSW-2800 Switch through Console port are as follows:
Connect the PC host and QSW-2800 Switch via a serial line, referring to
Figure 1-1 QSW-2800 Switch Login through Console Port;
Start PC hyper terminal by selecting [Start → All Programs →
Accessories → Communication], there will be a pop-up window of
connection description;
Create a new connection:
Input a name to the new created connection in the [Name] column,
e.g.,QSW-2800
Connection port setting. Select COM1 or COM2 port according to
physical connection of serial line, and click <OK>
