Chapter7 Security Configuration
6-16
Switch(config)#
6. Check multicast group table and egress interface table information.
Switch#show igmp-snooping group
Total Entry(s) : 1
Group Address MVlan Pre-join MemNum V3FilterMode
225.1.1.1 100 disable 1 invalid
Switch#show igmp-snooping egress-port
Total Entry(s) : 1
Group Address : 225.1.1.1
MVlan : 100
Source Address : *
Interface : ge-1/0/2
Type : static
Expires : ---
OutVlan : 100
V3 Mode : invalid
6.2.7.2 Example for IGMP Snooping
Network Requirement
Switch interface GE1/0/1 connects with the router of the multicast source side.
Interface GE1/0/2 connects with user host. It requires that the three host can receive
the multicast data with IP address of 225.1.1.1~225.1.1.2 in VLAN100 for long time by
configuring IGMP Snooping function.
Network Topology
