Chapter7 Security Configuration
6-23
Source Address : *
Interface : ge-1/0/2
Type : static
Expires : ---
OutVlan : 2
V3 Mode : invalid
Group Address : 225.0.0.2
MVlan : 100
Source Address : *
Interface : ge-1/0/3
Type : static
Expires : ---
OutVlan : 3
V3 Mode : invalid
Group Address : 225.0.0.3
MVlan : 100
Source Address : *
Interface : ge-1/0/2
Type : static
Expires : ---
OutVlan : 2
V3 Mode : invalid
Group Address : 225.0.0.3
MVlan : 100
Source Address : *
Interface : ge-1/0/3
Type : static
Expires : ---
OutVlan : 3
V3 Mode : invalid
6.2.7.4 Example for Controllable Multicast
Network Requirement
Switch interface GE1/0/1 connects with the router of the multicast source side.
Interface GE1/0/2 and GE1/0/3 connects with user host. It requires that the user of
